Vertical crusher introduction:

In the fertilizer production line, the vertical crusher is mainly in the raw material processing stage, it can further crush and refine the raw materials to achieve the fineness required for granulation, providing ideal particle size and texture for the subsequent mixing, granulation and other processes.

The vertical crusher is suitable for a variety of raw materials, including but not limited to limestone, cement clinker, mix, gypsum, gangue, etc., so it is able to handle a diversity of raw materials in the fertilizer production line.

Vertical crusher is a kind of fine crushing equipment without sieve bars and adjustable, which is suitable for the final crushing of a variety of materials.

Vertical crusher working principle:

The material enters from the inlet and collides with the high-speed rotating blades. In the process of impact, extrusion and crushing, the material is hit again to the inner wall of the shell after many times of impact. In such a cycle, the material is gradually changed into powder or granule, and finally discharged from the lower part.

Vertical crusher structure:

1.The lower frame: the bottom structure to support the whole equipment.

2.Shell: wrapped around the entire working area, the inner wall is lined with polypropylene board, to alleviate the sticky wall, not easy to clean up the problem.

3.Upper and lower shaft holders: The main shaft has upper and lower two bearing holders, which are used to support the rotation of the main shaft.

4. Spindle: the main rotating shaft driven by the motor, connected to the blade and hammer head.

5.Hammer head: installed in the spindle parts, collision with the material to complete the work of crushing.

6. Hammer head bracket: used to support and fix the hammer head.

7. Pulley: the key component in the transmission system, with the motor to drive the rotation of the spindle.

8. Motor frame: the bracket for installing the motor.

9. Feeding hopper: installed in the upper part of the shell, used to put materials.

10. the door: open the door of the shell, easy to disassemble and maintenance.

Advantages of vertical crusher:

1. Easy to operate: easy to operate, maintenance and cleaning is relatively simple.
2. Strong crushing performance: vertical crusher spindle is usually rotating at high speed, which makes the machine has a strong impact and crushing capacity. This high-speed rotation design helps to crush hard stones or other hard materials.
3. Strong applicability: suitable for a variety of raw materials, especially for high water content materials adaptability, not easy to clog, smooth discharging.
4. Optimized inner wall material: the inner wall of the machine shell is lined with polypropylene board, which alleviates the problem of sticking to the wall and not easy to clean.
5. 5.Efficient production: special steel linden made of chain knife head to improve production efficiency.

Overall, the vertical crusher in the fine crushing equipment with reasonable structure, easy to operate, adaptability and other characteristics, making it become a fertilizer manufacturing industry, mining, construction materials and other industries.
