disc granulator

  • By LANE
  • 06/02/2024

Disc granulator is a common granulation equipment, which is mainly used to make powdery raw materials into spherical particles through wet granulation. Disc granulator has the characteristics of low cost, high rate of granulation and uniformity of finished products.



Disc granulator working principle:

The working principle of disc granulator mainly includes feeding raw materials into the rotating disc, through the rotating movement and wet granulation, the raw materials are gradually gathered and bonded on the surface of the disc, and finally form spherical particles.



The main components of the disc granulator:

1、Granulating disc: rotating working part, used to hold and form granules, with radiant steel plate on the back, which is stable and durable to prevent deformation.

2、Adjusting part: used to adjust the tilting angle of the pelletizing disk, the key to control the size of granules.

3、Reducer:Provide rotating power.

4、Sprayer: Spray the right amount of liquid to make the raw material wet.

5、Scraper:Prevent the raw material from sticking to the wall and enhance the utilization rate of raw material.

6、Support frame and base: support the stable operation of the whole machine.



Disc granulator working process:

Raw material powder falls into the granulating disc, and after wet treatment or adding binder, the sprayer sprays the appropriate amount of liquid onto the raw material to make it become wet. Then, under the bonding effect of the liquid, the raw material rolls over and over on the rotating  granulating disc, gradually forming granules, which are finally thrown out through the inclined inclined plate.



Disc granulator is applicable to raw materials:

It is suitable for a variety of raw materials, including chemical fertilizer, organic fertilizer, grass ash, bio-fertilizer, and also for bentonite lamps to produce easily dissolved cat litter particles.

Disc granulator advantages:

1, high granulation rate:

Disc granulator adopts circular arc structure design, reasonable angle of granulation disk, the rate of balling can reach more than 93%, which ensures the production of regular, uniform particles.

2、Applicable to a variety of raw materials:

It is suitable for granulation of many kinds of raw materials, such as chemical fertilizer, organic fertilizer, grass ash, etc. It has good versatility and can meet the production needs of different fields.

3, simple structure and operation:

The structure of the disc granulator is relatively simple and easy to operate. This makes the equipment easy to maintain and operate. At the same time, it has a compact structure, covers a small area and does not require high site conditions.

4.Smooth startup and low impact:

The transmission system adopts flexible belt transmission, which starts smoothly and slows down the impact force, helping to improve the service life of the equipment.

Sturdy and durable structure:

5、Automatic material clearing device (scraper):

There is an automatic material clearing device designed on the top of the equipment, which can prevent the material from sticking to the wall and greatly improve the service life of the equipment.

6, Adjustability:

Disc granulator usually has a certain degree of adjustability, can be adjusted according to the characteristics of the raw material and production demand for humidity, rotation speed and other parameters, in order to obtain the ideal granulation effect.
